| Model |
IFP1617 |
| Product Name |
Hack Squat |
| Series |
IFP1 |
| Security |
ISO20957, GB17498-2008 |
| Max User Weight |
150 kg |
| Applicable Height Range |
155 cm – 195 cm |
| Resistance |
Plate Loaded |
| Function |
Monofunctional |
| Maximum Load |
175 kg * 2 |
| Targeted Muscle |
Quadriceps Femoris, Hamstring Muscles, Hip Muscle Group, Calf Muscle Group |
| Targeted Body Part |
Lower Limbs |
| Tube Specification – Function Part |
φ50.8*2.5 Stainless Steel 201, □50*100*3.0 |
| Tube Specification – Connection Part |
□50.8*2.5, □76.2*2.5 |
| Tube Specification – Bottom Part |
□50.8*76.2*2.5 |
| Tube Specification – Handle Tube Part |
φ25.2*2.5, φ16 |
| Pedal |
470*700mm Checkered Plates + Anti-skid Paint Coated |
| Toner |
BG304-331, DG506 |
| Plastic Color |
Black/Cold Gray/Yellow |
| Thickness of Back Cushion |
70 mm |
| Handle Bar Type |
Circular Tube Handle, Round rod adjusting handle |
| Handle Bar Cover |
TPV (Aluminum baffle ring and aluminum head), Yellow PVC adjusting handle |
| Main Pulley Size |
φ57 Roller |
| Main Pulley Material |
POM |
| Guide Rod Specification |
Guideway φ50.8*2.5 |
| Guide Rod Material |
Stainless steel 201 |
| Standardized Parts |
Medium Carbon Steel (8.16 grade, Zinc Plating-black) |
| Main Bearing |
GB2766203-2Z |
| Hook |
10mm chemical nickel-plating |
| Barbell Plate Storage Bar |
4 |
| Barbell Bar Diameter |
50 mm |
| Maximum Storage Weight of Single Barbell Plate Storage Bar |
100 kg |
| Product Dimension |
1982*1485*1318 mm |
| Net Weight |
100.6 kg |
| Gross Weight |
128.2 kg |
| Number of Packages |
2 |
| Packaged Form |
Carton |
| Package Size and Weight |
1515*905*480, 1865*355*230 |
| 20′40 HQ40 GP |
60 |
